RH113(T) Wired Vibration Temperature Sensor

RH113(T) is a dedicated low-frequency accelerometer line with 500 mv/g high sensitivity, tailored for low-speed equipment monitoring—ideal for low-speed rotors, main bearings, and gearbox inputs. Unlike standard sensors, it combines ultra-low 0.1Hz frequency response with military-grade ruggedness, amplifying weak vibration signals to deliver exceptional signal clarity. This design ensures reliable capture of subtle low-frequency anomalies, empowering precise equipment health diagnostics.

Frequency range: 0.1Hz～10KHz(±3dB)
Sensitivity: 500mv/g
Measuring range: ±10g
Temperature measuring range: -40~120℃
IP grade: IP68
ATEX
Built-in IEPE circuit, isolated output, constant current power supply.
Laser-sealed welding, strong and reliable.

RH113(T) Wired Vibration Temperature Sensor Features

Low-Frequency & High-Sensitivity Performance

0.1Hz-10kHz wide frequency response and 500mv/g high sensitivity enable accurate capture of low-frequency, weak vibrations, perfect for low-speed equipment monitoring.
Rugged & Harsh-Environment Adaptability

316L stainless steel housing, laser welding, IP68 protection, and -55℃~+125℃ operating range resist corrosion, dust, and water, thriving in harsh industrial sites.
Precise & Reliable Data Output

±10g peak range, ≤1% amplitude linearity, and internal shielding ensure stable signal transmission with minimal interference, supporting accurate equipment health analysis.
